UR-W1006C
UR-W1006C offers a generous 22.8m lifting height and 21.93 working radius, yet at only 2000mm wide, it still retains class-beating minimal dimensions for working in restricted areas.
UR-W1006C also has a Pick & Carry function which enables it to travel with loads up to 1500kg as well as a full interlocking system and configurable outriggers.
- Max. Hook Height:: 22.8m
- Max. Lifting Capacity:: 10.14t at 3.0m
- Mass of Crane:: 13800kg
- Max. Working Radius:: 21.93m
| MODEL | UR-W1006C |
|---|---|
| Max. Lifting Capacity | 10.14t at 3.0m |
| Max. Working Radius | 21.93m |
| Max. Hook Height (Approx.) | 22.8 m |
| Max. Boom Length | 23.01m |
| Min. Boom Length | 5.75m |
| Boom Sections | 6 |
| Boom Raising Angle | Min. 0 to Max. 80° |
| Slewing Angle | 360° Continuous |
