UR-W295C
UR-W295C offers a generous 8.8m lifting height and 8.41working radius, yet at only 2000mm wide, it still retains class-beating minimal dimensions for working in restricted areas.
UR-W295C features an easy and quickly installed searcher hook and fly jib options that will increase working radius and lifting height more. Its outriggers allow independent multi-angle configurations to be placed at the best position whether in restricted or confined areas.
- Max. Hook Height:: 8.8m
- Max. Lifting Capacity:: 2.93t at 1.4m
- Mass of Crane:: 1850kg
- Max. Working Radius:: 8.41m
| MODEL | UR-W295C |
|---|---|
| Max. Hook Height | 2.93t at 1.4m |
| Max. Working Radius | 8.41m |
| Max. Hook Height (Approx.) | 8.8m |
| Max. Boom Length | 8.65m |
| Min. Boom Length | 2.53m |
| Boom Sections | 5 |
| Boom Raising Angle | Min. 0 to Max. 78° |
| Slewing Angle | 360° Continuous |
